3M MS2 User Manual

38
8.6.5.3.5 26 AWG Three Bank Super-Mate Apparatus Splice*
Main Cable
Pair Count Zero 100 200 300 600 900 1200 1500 1800 2100
300 2.2 3.2 3.6 3.6
600 3.1 4.0 4.4 4.4 5.7
900 4.0 4.8 5.1 5.1 6.2 6.5
1200 4.9 5.5 5.8 5.8 6.8 7.2 7.8
1500 5.7 6.3 6.5 6.6 7.3 8.0 8.4 9.1
1800 6.6 7.1 7.3 7.3 7.9 8.6 9.0 9.5 10.0
2100 7.3 7.8 8.0 8.0 8.4 9.2 9.5 9.9 10.4 10.6
2400 7.9 8.3 8.5 8.5 8.9 9.6 9.9 10.3 10.7 11.2
2700 8.3 8.7 8.9 8.9 9.3 9.9 10.2 10.8 11.4 11.9
3000 8.7 9.0 9.2 9.3 9.7 10.2 10.9 11.3 11.8 12.4
3600 9.2 9.6 9.8 9.8 10.2 10.6 11.6 12.0 12.6 13.2
Straight Splice Measurement in Inline Configuration
(4005-DPM Super-Mate Modules)
Number of Apparatus Pairs
Unilength Cofiguration (4005-DPM Super-Mate Modules)
VALUES IN INCHES
*NOTE: For 22 AWG conductors, increase values by 25%
For 24 AWG conductors, increase values by 12%
If sealant boxes are used, increase values approximately 25%
8.6.5.3.6 26 AWG Four Bank Super-Mate Apparatus Splice*
Main Cable
Pair Count Zero 100 200 300 400 600 900 1200 1500 1800 2100
400 2.3 2.7 3.1 3.7 3.9
600 2.7 3.1 3.5 4.0 4.2 5.1
900 3.3 3.6 4.0 4.5 4.7 5.6 6.3
1200 3.9 4.2 4.5 5.0 5.2 6.0 6.5 7.1
1500 4.5 4.8 5.1 5.5 5.8 6.5 7.0 7.6 7.8
1800 5.0 5.4 5.6 6.0 6.2 7.0 7.6 8.0 8.4 8.7
2100 5.6 5.9 6.1 6.5 6.7 7.5 8.2 8.7 9.0 9.4 9.7
2400 6.2 6.5 6.6 7.0 7.2 8.0 8.8 9.4 9.8 10.6 10.9
2700 6.7 7.0 7.2 7.5 7.7 8.5 9.3 9.8 10.3 11.2 11.5
3000 7.3 7.6 7.7 8.0 8.3 8.9 9.8 10.3 10.8 11.6 11.9
3600 8.5 8.8 8.8 9.1 9.3 9.9 10.7 11.2 11.8 12.4 12.7
Straight Splice Measurement in Inline Configuration
(4005-DPM Super-Mate Modules)
Number of Apparatus Pairs
Unilength Cofiguration (4005-DPM Super-Mate Modules)
VALUES IN INCHES
*NOTE: For 22 AWG conductors, increase values by 25%
For 24 AWG conductors, increase values by 12%
If sealant boxes are used, increase values approximately 25%
