5.0 Use of Tools and Modules

5.1 Rig set-up as follows:

5.1.1 Attach support tube to cable.

5.1.6 Insert pedestal in head clamp.

75426

5.1.7 Splice back, bottom group first.

For inline splicing, adjust head(s) to group

being handled.

Note: Splice head should be higher than group

being spliced.

5.1.9 In the 4041 Splice Head, the gold splice adapter

is used with the Super-Mini Modules only.

75469

75470

75471

75472

75430

832595

832593

5.1.2 Attach buckle.

5.1.3 Tighten strap.

5.1.4 Attach traverse clamp assembly.

5.1.5 Slide head clamp on traverse bar.

75420

75421

75419

832593

5.1.8 Set retainer spring to proper wire gauge.
