6
ENGLISH
Calibration
A calibration of the handheld TRIOS scanner is required before using TRIOS
for the first time and every 8 days during regular use or to compensate for
thermal variation and aging effects due to wear. To perform the calibration,
place the Calibration Tip on the Scanner Tube, go to the Settings page in the
the TRIOS software, select TRIOS → Scanner Management → 3D calibrate
scanner, and then follow the on-screen instructions.
For a more detailed description of the calibration,
please refer to the TRIOS online help.
Color Calibration
A color calibration of the handheld scanner is required before each scan in
order to get optimal colors.
1. Attach a cleaned and sterilized scanner tip on the scanner tube.
2. Remove the sleeve from the color calibration target.
3. Mount the color calibration target on the color calibration adaptor with
the color side facing up.
4. Attach the color calibration adaptor on the cleaned and sterilized
scanner tip.
5. Go to the Settings page in the TRIOS software, select TRIOS → Scanner
Management → Color calibrate scanner, and then follow the on-screen
instructions, which will also include validation of the performed color
calibration.
6. For a more detailed description of the color calibration, please refer to
the TRIOS Online help.
Proper shutdown
Inside the TRIOS software click on the “Close” button and select “Shutdown”
or press the standby button. The standby button turns off to confirm that
the system is shut down.
CAUTION
When switching off the system, allow enough time for it to
shut down properly before disconnecting the mains cable.
IMPORTANT NOTICE
The standby button can also be used to force TRIOS® to
shut down in case the screen stops responding. To force a
shutdown, push and hold the standby button pressed for
about 5 seconds. Then, restart the system.
4.9 Starting TRIOS Online Help
The TRIOS online help can be started from TRIOS software by clicking on the
“Help” button and choosing “User Manual”.
4.10 TRIOS System Environment
IMPORTANT NOTICE
Operating Conditions
Ambient temperature range: +15 – +30 °C
Relative humidity: 10 – 85 % (Non-condensing)
Atmospheric pressure: 800 – 1100 hPa.
The scanner should be used in an environment maintaining
a consistent room temperature.
IMPORTANT NOTICE
Storage Conditions
Ambient temperature range: -10 – +60 °C
Relative humidity: 10 – 85 % (Non-condensing)
Atmospheric pressure: 800 – 1100 hPa.
IMPORTANT NOTICE
Transport Conditions
Ambient temperature range: -10 – +60 °C
Relative humidity: 10 – 85 % (Non-condensing)
Atmospheric pressure: 620 – 1200 hPa.
4.11 Technical specifications
Light source
specifications
Do not view directly with optical instruments, such
as spectacle microscopes. The product complies
with EN (IEC) 62471 Photobiological safety of lamps
and lamp systems.
Sterilization
method
Scanner tips are autoclavable.
Power input C4.0/ C4.1 MOVE/MOVE+ cart (for S2A)
Power input: 100-240 VAC, 50/60 Hz, 180 VA max
Insulation class: class I
C3BP Battery charger:
Power input: 100-240 V, ~0.3-0.7A, 50/60 Hz
Protection class: IP20
Insulation class: Class II
S2-2 scanner:
Wireless, battery powered
3Shape TB-02 Rechargeable Battery:
3.6 V, 2000mAh, 7 Wh
3Shape TB-03 Reachargable Battery:
3.6 V, 3450 mAh, 12 Wh
Wireless
Module
The scanner contains FCC ID: PD97265NG
IEEE 802.11AC module
Wireless
Transmit Power
Maximum 100 mW
Wireless
Frequency Band
2.401-2.483 GHz
5.15–5.725 GHz
(actual frequencies are dependent on what is
enabled for the product and local regulations.)
5. Safety and Warnings
5.1 Prerequisites
CAUTION
Read all instructions carefully including all warnings and
caution notices. You must comply with the warnings in
this manual to prevent injury to persons and damage to
equipment. Proper functionality and safety can only be
guaranteed if the safety precautions in this safety guide
and on the TRIOS IOS system are observed.
