Hardware Installation
Table 22 Mounting Set for Subrack B
NTM 144 263 Mounting set for subrack B
Pos. Title/Function Product Number Quantity
H Air plate, front (used in subrack A
if the two subracks are mounted in
one cabinet)
SXA 112 2331/1
1
I Air plate, rear (used in subrack A
if the two subracks are mounted in
one cabinet)
SXA 112 2332/1
1
C SCREW M 6X16 78/SBA 121
060/0160
4
A CAPTIVE NUT M6 SBM 173 060/03
4
F SCREW M 4X6 24/SBF 228
040/0060
2
G* CABLE LUG (only used if the two
subracks are mounted in separate
cabinets)
SNG 804 23
1
K* LABEL FOR ESD (only used if
the two subracks are mounted in
separate cabinets)
SVB 129 05/2
1
* For information, Page 23 .
4.8.1 Mounting the Lower Air Plate
Before installing subrack B, install the lower air plate in the subrack. Perform
the following steps:
57
6/1531-ASP 113 01 Uen J2 2008-07-17
