The main ones are listed below:
This symbol indicates a risk of
electric shock.
This symbol shows the
minimum operating temperature
of the charge status control
unit. The device can be used
from -30°C to +50°C. If the
device is not used and must be
stored, the temperature must
be between -40°C and +70°C.
Exceeding these temperature
values may damage the device.
This symbol on the label
indicates that the charge status
control unit does not disconnect
the earthing cable.
This symbol indicates that
the charging unit should not
be placed in the waste if it no
longer works: for disposal refer
to the environmental regulations
in force in the country in which
it circulates.
This symbol prompts you to
read the instructions in this
publication carefully before
using the charging cable.
LABEL ON THE DOMESTIC PLUG
END OF THE CABLE
There is a summary label on the cable,
domestic plug side, fig.6 where some
symbols are applied.
6 J0A6115E
