IN AN EMERGENCY
198
REPLACING AN
EXTERNAL BULB
FRONT LIGHT CLUSTERS
The front light clusters contain side/tail
lights, dipped headlights, main beam
headlights and direction indicator
bulbs.
LED front direction indicators
Contact a Dealership for replacement.
LED side direction indicators
Contact a Dealership for replacement.
LED dipped beam/main beam
headlights
Contact a Dealership for replacement.
LED side lights/daytime running
lights (DRL).
Contact a Dealership for replacement.
REAR LIGHT CLUSTERS
These contain the functions of the
tail lights, brake lights and direction
indicators. The reversing lights and rear
fog lights are located instead in the rear
bumper.
The tail, brake, third brake lights and
the direction indications are of the
LED type. Contact a Dealership for
replacement.
REVERSING LIGHT/REAR FOG
LIGHT
To replace the reversing and rear fog
light, access the bulb holder through
the lower part of the rear bumper
fig. 187.
187 AB0A0578
rotate the bulb holder (A) fig. 188
anticlockwise and extract it. Undo
the outer bulb holders to replace the
reversing lights. Undo the central bulb
holder to replace the rear fog light;
release the bulb and replace it;
188 F0S1165
refit the bulb/bulb holder (A) by
turning it clockwise.
THIRD BRAKE LIGHTS
The third brake lights are LED-type.
Contact a Dealership for replacement.
NUMBER PLATE LIGHTS
The number plate lights are LED-type.
Contact a Dealership for replacement.
REPLACING INTERIOR
BULBS
Inside ceiling light
To replace the bulbs, proceed as
follows:
operate in the points indicated by
the arrows and remove ceiling light (A)
fig. 189 complete with its frame;
189 AB0A0543
