201
insert the sealant cartridge (A)
into the corresponding compressor
compartment (B) and press it down
hard. Remove the speed limit sticker
(C) and apply it in a clearly visible
position;
wear the gloves;
remove the cap from the tyre valve
and connect and screw the transparent
tube of the sealing fluid (D) onto the
valve.
If a 250 ml cartridge is present the
housing of the transparent tube is
provided with a removable ring to
facilitate extraction;
make sure that the ON/ OFF button
(E) fig. 195 is in the off position (button
not pressed);
194 F0S1294
insert the electrical connector (C)
fig. 194 in the 12 V power socket of the
car and start the engine;
operate the compressor by pressing
the ON/OFF button (E) fig. 195. When
the pressure gauge (G) reaches the
recommended pressure (see the
“Wheels” chapter in the “Technical
Data” section) or the pressure
indicated on the specific label) stop the
compressor by pressing the ON-OFF
button again;
disconnect the cartridge (A) fig. 196
from the compressor, by pressing
the release button (H) and lifting the
cartridge upwards.
195 F0S1262
196 F0S1263
If the pressure gauge (G) fig. 195
indicates a pressure lower than 1.8
bar (26 psi) 15 minutes after starting
the compressor, switch off the
compressor, disconnect the sealing
fluid tube (D) fig. 193 from the tyre valve
and remove the cartridge (A) from the
compressor.
Move the car by approximately 10
metres to allow the distribution of
the sealant. Stop the vehicle safely,
operate the electric parking brake
and restore pressure using the black
inflation pipe (I) fig. 197 to reach the
required pressure. If also in this case,
the pressure is lower than 1.8 bar
(26 psi) 15 minutes after turning on,
do not resume driving but contact a
Dealership. After driving for about 8 km
/ 5 miles fig. 198, move the car to a
safe and suitable area and engage
the electric parking brake. Take the
Repair procedure
Proceed as follows:
