IN AN EMERGENCY
202
compressor and restore pressure using
the black inflation tube (I).
197 F0S1264
198 F0S1293
If the pressure shown is higher than 1.8
bar ( 26 psi), restore the pressure and
carefully drive to a Dealership in the
shortest possible time. Otherwise, if the
pressure is less than 1.8 bar (26 psi),
do not resume driving, but contact a
Dealership.
207)
Inflation procedure
Proceed as follows:
stop the car safely, as described
above, and operate the electric parking
brake;
extract the black inflation tube and
screw it firmly onto the tyre valve. Then
follow the instructions below. Press
the air release button to adjust any
excessive tyre pressure (see "Repair
procedure" paragraph).
Cartridge replacement
Proceed as follows:
only use original cartridges, which
can be purchased from a Dealership;
to remove the cartridge, press the
release button and lift it (see description
above).
OPT2 KIT DESCRIPTION
208) 209) 210)
199 F0S0822
(A) Pressure gauge
(B) Instruction label
(C) On/Off button
200 F0S0823
(D) Air pipe
(E) Deflation button
(F) Power supply cable / 12V plug
201 F0S0824
(G) Cap for the sealant bottle
(H) Sealant bottle and expiry date
(I) Speed label
