203
Description
202 F0S0825
The quick tyre repair kit fig. 202 is
located in the boot or in the toolbox
and consists of a compressor (B) and
a cartridge containing sealing fluid (A)
and an adhesive sticker (C) with the
wording "Max km 80Km/h", which is to
be placed in a clearly visible position
(e.g. instrument panel) after the tyre
repair.
Repair procedure
203 F0S0826
Proceed as follows:
take the kit, detach the speed limit
sticker (I) fig. 201 and apply it in a
clearly visible position fig. 203
204 F0S0834
open the cap on the compressor,
engage the cartridge and turn a quarter
turn clockwise, fig. 204
remove the cap from the tyre valve
and screw the black compressor tube
onto the valve
make sure that the ON/OFF button
is in the OFF position (button in 0
position)
205 F0S0835
insert the electrical connector
fig. 205 into the 12V socket on the car
