Fault protection
The 266 PdP electronic implements the circuitry for the fault
current protection. Whenever a fatal failure occurs and the
current consumption increase over the 20 mA, this circuitry
provides to disconnect the device from the bus, in order to
preserve alive the rest of the bus that, otherwise, could drop
down with all the other connected devices.
On board switches
On the electronic unit (behind the Local Display when installed)
there are 4 switches, with the following functionality:
SW 1 – Replace Mode
In UP position (1) it enables the Replacement operation. It must
be used in combination with the SW 2 that selects which part of
the Transmitter is going to be replaced.
SW 2 – Replace Mode - details
In UP position (1) it selects the Sensor Replacement. The entire
transmitter’s configuration data are kept valid in the
electronics and copied into the memory of the new sensor once
it is connected. In OFF position (0) it selects the Electronics
Replacement. The entire transmitter’s configuration data are
kept valid in the sensor memory and copied into the memory of
the new electronics once it is connected.
SW 3 – Push Buttons Mode
This switch selects the type of operation executed with the
housing push buttons located under the type plate. In UP
position (1) it enables the push buttons for the ranging
operation. In OFF position (0) it enables the push buttons for
the PV bias Set/Reset operations.
SW 4 – Simulation Mode
This switch in UP position (1) enables the Standard Simulation
feature mandatory for FF devices.
266FF can simulate diagnostic conditions by writing the error
to be simulated into “RB_FD_SIMULATE” (index 67) or can
simulate the value and status output of the PRTB going in input
to the AI, by writing into “AIx_SIMULATE” (index 9).
However, this writing has effect only if the HW switch 4 has
been previously moved in ON position (SIMUL MODE ENABLE).
Factory default configuration
The on-board switches are set by default in OFF position (0).
Therefore:
SW 1 – Replace Mode is disabled.
SW 2 – Replace Mode - details on New Electronic but with no
effect since SW 1 is on OFF position.
SW 3 – Push Buttons Mode on OFF position (0). With this
configuration, the external non-intrusive push buttons perform
the PV bias Set/Reset function by default.
SW 4 – Simulation Mode on OFF position (0). The Simulation
mode is disabled. It can be performed only when the hardware
dip-switch is alligned to the same software functionality.
