Installation checklist and start-up
105
Fixed parameters with the ACS800-37
When the IGBT Supply Control Program is loaded into the ACS800-37, the following
parameters receive the default values given in the table below.
31.02 TRIAL TIME Defines the time for the automatic fault reset function. See parameter
31.01.
R 30 s
1.0 … 180.0 s Allowed resetting time 100 …
18000
31.03 DELAY TIME Defines the time that the drive will wait after a fault before attempting
an automatic reset. See parameter 31.01.
R0 s
0.0 … 3.0 s Resetting delay 0 … 300
31.04 OVERCURRENT Activates/deactivates the automatic reset for the line converter
overcurrent fault.
BNO
NO Inactive 0
YES Active 65535
31.05 OVERVOLTAGE Activates/deactivates the automatic reset for the intermediate link
overvoltage fault.
BNO
NO Inactive 0
YES Active 65535
31.06 UNDERVOLTAGE Activates/deactivates the automatic reset for the intermediate link
undervoltage fault.
BNO
NO Inactive 0
YES Active 65535
Parameter Default value If changed,
11.01 DC REF SELECT FIELDBUS the default values will be
restored on the next power-
up
11.02 Q REF SELECT PARAM 24.02
98.01 COMMAND SEL MCW. Note: If par. 16.15 I/O
START MODE is set to DI2 LEVEL,
the default value is changed to I/O
on the next RMIO board power-up.
98.02 COMM. MODULE INVERTER
201.09 PANEL DRIVE ID 2
202.01 LOCAL LOCK TRUE
30.02 EARTH FAULT FAULT the default values will not
be restored on the next
power-up. Do not change
them. If the default values
are changed, the drive will
not function.
70.01 CH0 NODE ADDR 120
70.19 CH0 HW CONNECTION RING
70.20 CH3 HW CONNECTION RING
71.01 CH0 DRIVEBUS MODE NO
No. Name/Value Description T./FbEq Def.
