Technical data
123
Technical data
What this chapter contains
This chapter contains the technical specifications of the drive, e.g. ratings, frame
sizes and technical requirements, provisions for fulfilling the requirements for CE
and other markings, and warranty information.
IEC ratings
The ratings for the ACS800-37 with a 50 Hz supply are given below. The symbols
are described below the table.
ACS800-37 type
Nominal
ratings
No-over-
load use
Light-
overload use
Heavy-duty
use
Heat dissi-
pation
Air
flow
Noise
level
I
cont.max
A
I
max
A
P
cont.max
kW
I
2N
A
P
N
kW
I
2hd
A
P
hd
kW kW m
3
/h dBA
Three-phase supply voltage 380 V, 400 V or 415 V
ACS800-37-0060-3 120 168 55 114 55 88 45 1.8 500 73
ACS800-37-0070-3 150 234 75 142 75 117 55 2.4 500 73
ACS800-37-0100-3 165 264 90 157 75 132 75 2.8 500 73
ACS800-37-0140-3 202 293 110 194 90 151 75 6 1300 74
ACS800-37-0170-3 250 363 132 240 132 187 90 7 1300 74
ACS800-37-0210-3 292 400 160 280 160 218 110 8 3160 75
ACS800-37-0260-3 370 506 200 355 200 277 132 10 3160 75
ACS800-37-0320-3 469 642 250 450 250 351 200 13 3160 75
ACS800-37-0390-3 565 773 315 542 315 423 250 16 3160 75
ACS800-37-0510-3 730 1000 400 701 355 546 250 23 3160 75
ACS800-37-0640-3 919 1258 500 882 500 688 355 24 6400 77
ACS800-37-0770-3 1111 1521 630 1067 630 831 450 31 6400 77
ACS800-37-0960-3 1379 1888 800 1324 710 1031 560 43 6400 77
ACS800-37-1070-3 1535 2102 900 1474 800 1149 630 46 10240 78
ACS800-37-1430-3 2056 2814 1200 1973 1100 1538 800 63 10240 78
ACS800-37-1810-3 2610 3573 1600 2506 1400 1953 1100 83 12800 79
Three-phase supply voltage 380 V, 400 V, 415 V, 440 V, 460 V, 480 V or 500 V
ACS800-37-0070-5 120 168 75 114 75 88 55 2.4 500 73
ACS800-37-0100-5 139 234 90 132 90 114 75 2.8 500 73
ACS800-37-0120-5 156 264 110 148
(1
90 125 75 3.4 500 73
ACS800-37-0170-5 200 291 132 192 132 150 90 6 1300 74
ACS800-37-0210-5 245 355 160 235
(2
160 183 110 8 1300 74
ACS800-37-0260-5 302 438 200 289
(3
200 226 132 9 3160 75
ACS800-37-0320-5 365 530 250 350
(4
250 273 160 11 3160 75
ACS800-37-0400-5 455 660 315 437 315 340 200 14 3160 75
ACS800-37-0460-5 525 762 355 504 355 393 250 16 3160 75
ACS800-37-0510-5 595 863 400 571 400 445 315 18 3160 75
ACS800-37-0610-5 700 1016 500 672 450 524 315 23 3160 75
ACS800-37-0780-5 892 1294 630 856 630 667 450 26 6400 77
ACS800-37-0870-5 1005 1458 710 965 630 752 500 32 6400 77
ACS800-37-1160-5 1338 1941 900 1284 900 1001 710 44 6400 77
ACS800-37-1330-5 1528 2217 1120 1467 1120 1143 800 46 10240 78
