Mechanical installation
45
…by fork-lift or pallet truck
…on rollers
(Not allowed with Marine versions)
Laying the unit on its back
The centre of gravity may be quite high. Be therefore careful
when transporting the unit. Tilting the cabinets must be
avoided.
The units are to be moved only in the upright position.
If using a pallet truck, check its load capacity before
attempting to move the unit.
Remove the wooden bottom frame which is part
of the shipment.
Lay the unit on the rollers and move it carefully
until close to its final location.
Remove the rollers by lifting the unit with a
crane, fork-lift, pallet truck or jack as described
above.
If the cabinet needs to be laid on its back, it
must be supported from below beside the
cubicle seams as shown.
Cabinet back panel Support
