Technical data

129

AC fuses

Notes:

• Larger fuses must not be used.

• Fuses from other manufacturers can be used if they meet the ratings.

• The recommended fuses are for branch circuit protection per NEC as required for

UL approval.

Drive type

AC fuse information

Qty I

aR, IEC aR, UL Recognized

Bussmann Ferraz Shawmut Bussmann Ferraz Shawmut

400 V

ACS800-37-0060-3 3 160 170M3814 – 170M3014 –

ACS800-37-0070-3 3 200 170M3815 – 170M3015 –

ACS800-37-0100-3 3 250 170M3816 – 170M3016 –

ACS800-37-0140-3 3 315 170M3817 – 170M3017 –

ACS800-37-0170-3 3 400 170M5808 – 170M5008 –

ACS800-37-0210-3 3 450 170M5809 6.9URD2PV0450 170M5059 –

ACS800-37-0260-3 3 630 170M6810 6.9URD3PV0630 170M6210 –

ACS800-37-0320-3 3 800 170M8545 6.9URD3PV0800 170M6212 –

ACS800-37-0390-3 3 1000 170M6814 6.9URD3PV1000 170M6214 –

ACS800-37-0510-3 3 1000 170M6814 6.9URD3PV1000 170M6214 –

ACS800-37-0640-3 3 1600 170M6419 6URD33TTF1600 170M6419 6URD33TTF1600

ACS800-37-0770-3 3 2000 170M6421 5.5URD33TTF2000 170M6421 5.5URD33TTF2000

ACS800-37-0960-3 3 2000 170M6421 5.5URD33TTF2000 170M6421 5.5URD33TTF2000

ACS800-37-1070-3 6 1600 170M6419 6URD33TTF1600 170M6419 6URD33TTF1600

ACS800-37-1430-3 6 1600 170M6419 6URD33TTF1600 170M6419 6URD33TTF1600

ACS800-37-1810-3 6 2000 170M6421 5.5URD33TTF2000 170M6421 5.5URD33TTF2000

500 V

ACS800-37-0070-5 3 160 170M3814 – 170M3014 –

ACS800-37-0100-5 3 200 170M3815 – 170M3015 –

ACS800-37-0120-5 3 250 170M3816 – 170M3016 –

ACS800-37-0170-5 3 315 170M3817 – 170M3017 –

ACS800-37-0210-5 3 400 170M5808 – 170M5008 –

ACS800-37-0260-5 3 450 170M5809 6.9URD2PV0450 170M5059 –

ACS800-37-0320-5 3 630 170M6810 6.9URD3PV0630 170M6210 –

ACS800-37-0400-5 3 800 170M8545 6.9URD3PV0800 170M6212 –

ACS800-37-0460-5 3 1000 170M6814 6.9URD3PV1000 170M6214 –

ACS800-37-0510-5 3 1000 170M6814 6.9URD3PV1000 170M6214 –

ACS800-37-0610-5 3 1000 170M6814 6.9URD3PV1000 170M6214 –

ACS800-37-0780-5 3 1600 170M6419 6URD33TTF1600 170M6419 6URD33TTF1600

ACS800-37-0870-5 3 2000 170M6421 5.5URD33TTF2000 170M6421 5.5URD33TTF2000

ACS800-37-1160-5 3 2000 170M6421 5.5URD33TTF2000 170M6421 5.5URD33TTF2000

ACS800-37-1330-5 6 1600 170M6419 6URD33TTF1600 170M6419 6URD33TTF1600

ACS800-37-1820-5 6 1600 170M6419 6URD33TTF1600 170M6419 6URD33TTF1600

ACS800-37-2200-5 6 2000 170M6421 5.5URD33TTF2000 170M6421 5.5URD33TTF2000

690 V

ACS800-37-0170-7 3 250 170M3816 – 170M3016 –

ACS800-37-0210-7 3 315 170M3817 – 170M3017 –

ACS800-37-0260-7 3 315 170M3817 6.9URD1PV0315 170M3017 –

ACS800-37-0320-7 3 450 170M5809 6.9URD2PV0450 170M5059 –

ACS800-37-0400-7 3 450 170M5809 6.9URD2PV0450 170M5059 –

ACS800-37-0440-7 3 630 170M6810 6.9URD3PV0630 170M6210 –

ACS800-37-0540-7 3 630 170M6810 6.9URD3PV0630 170M6210 –

ACS800-37-0790-7 3 1000 170M6414 6.9URD32TTF1000 170M6414 6.9URD32TTF1000

ACS800-37-0870-7 3 1250 170M6416 – 170M6416 –

ACS800-37-1160-7 3 1250 170M6416 – 170M6416 –

ACS800-37-1330-7 6 1000 170M6414 6.9URD32TTF1000 170M6414 6.9URD32TTF1000

ACS800-37-1510-7 6 1000 170M6414 6.9URD32TTF1000 170M6414 6.9URD32TTF1000

ACS800-37-2320-7 6 1250 170M6416 – 170M6416 –

ACS800-37-2780-7 9 1250 170M6416 – 170M6416 –

ACS800-37-3310-7 9 1250 170M6416 – 170M6416 –

PDM-184674-G5
