Mechanical installation
31
Push-through mounting
An installation kit is available for push-through mounting. The kit enables the
installation of the drive module in the wall of a cooling air duct so that part of the
module protrudes into the duct.
Keep the screws removed during the procedure – they will later be used to fasten
the push-through mounting parts.
Lower collar
Lateral supports
Upper collar
Lifting lug
