Technical data
71
Technical data
What this chapter contains
This chapter contains the technical specifications of the drive, e.g. the ratings, sizes
and technical requirements, and provisions for fulfilling the requirements for CE and
other markings.
Ratings
The nominal ratings for the ACSM1-04 with 50 Hz and 60 Hz supplies are given
below.
Drive type
ACSM1-04xx…
Frame
size
Input ratings Output ratings
I
1N
I
2N
I
2cont4k
I
2cont8k
I
2max
P
N
AAAAAkWHP
-110A-4 E 107 110 110 75 165 55 75
-135A-4 E 131 135 135 90 202 75 100
-175A-4 E 171 175 175 115 282 90 125
-210A-4 E 205 210 210 135 326 110 150
PDM-00425726
I
1N
Nominal input current (rms) at 40 °C (104 °F).
I
2N
Nominal output current at 40 °C (104 °F).
I
2contxk
Continuous output current at a switching frequency of 4 or 8 kHz at 40 °C (104 °F).
P
N
Typical motor power.
I
2max
Maximum short-time output current. See section Cyclic loads below.
To achieve the rated motor power given in the table, the rated current of the drive must be higher than
or equal to the rated motor current.
The DriveSize dimensioning tool available from ABB is recommended for selecting the drive, motor
and gear combination for the required motion profile.
