ABB AX400 Series User Manual

Single and dual input analyzers for pH/Redox (ORP)
AX416, AX436, AX460, AX466 & AX468 2 Operation
8 IM/AX4PH Rev. P
2.3.3 Single Input Redox (ORP)
Measured Values
Millivolts.
Temperature.
Offset – Sensor A
Displays the offset value for the sensor set in
A: Adjust Offset – see Section 4.1.3,
page 22.
See Section 3.1, page 12.
See Section 4.1, page 19.
A3: Type set to Wash (Section 5.5) – see Section 2.3.6, page 11.
A3: Type not set to Wash (Section 5.5) – return to top of page.
Redox (ORP)
404
mV
25.6
Deg.C
A: mV Offset
0
mV
Redox (ORP)
VIEW SETPOINTS
SENSOR CAL.
Wash Function

ABB AX400 Series Specifications

General

Display	LCD with backlight
Output	4 to 20 mA, HART
Process connection	Flanged
Lining material	PTFE, PFA
Electrode material	Stainless steel, titanium
Communication	HART
