ABB AX400 Series User Manual

Single and dual input analyzers for pH/Redox (ORP)
AX416, AX436, AX460, AX466 & AX468 3 Operator Views
12 IM/AX4PH Rev. P
3 Operator Views
3.1 View Set Points
Note. The parameter names and units of measurement displayed in the View Set Points page depend on the Probe Type settings
for Sensors A and B – see Section 5.3, page 30. Those shown below are given as examples only.
View Set Points
This page shows alarm set points. The value of each of the set points is shown,
together with the name of the parameter it is assigned to.
Alarm assignments, set point values and relay/LED actions are programmable – see
Section 5.4, page 33.
Sensor A (pH), Alarm 1 Set Point
Sensor A (Temperature), Alarm 2 Set Point
Sensor B (pH), Alarm 3 Set Point – Dual input analyzers only
Sensor B (Temperature), Alarm 4 Set Point – Dual input analyzers only
Note. Alarm 4 available only if option board fitted and analog features enabled – see
Section 7.3, page 57.
Alarm 5 Set Point
Note. Alarm 5 available only if option board fitted and analog features enabled – see
Section 7.3, page 57.
See Section 3.2, page 14.
See Note on next page.
8.30
pH
A1: Setpoint
Sen.A
Temp.A
VIEW SETPOINTS
-----
35.0
Deg.C
A2: Setpoint
Sen.B
6.80
A3: Setpoint
Temp.B
55.0
Deg.C
A4: Setpoint
-----
Off
A5: Setpoint
VIEW OUTPUTS
SENSOR CAL.
Security Code
CONFIG. DISPLAY
VIEW SETPOINTS
pH
