ABB AX400 Series User Manual

Single and dual input analyzers for pH/Redox (ORP)
AX416, AX436, AX460, AX466 & AX468 3 Operator Views
IM/AX4PH Rev. P 13
Note. The menu displayed when pressing the key from the Operator View pages depends on analyzer configuration, i.e.:
Single Input Analyzers
Probe Type set to pH
or
Probe Type set to Redox or ORP and Enable Cals set to Yes (Section 5.3) – see Section 4.1, page 19.
Probe Type set to Redox or ORP and Enable Cals set to No (Section 5.3) and Alter Sec. Code not set to zero
(Section 5.8) – see Section 5.1, page 28.
Probe Type set to Redox or ORP and Enable Cals set to No (Section 5.3) and Alter Sec. Code set to zero
(Section 5.8) – see Section 5.2, page 29.
Dual Input Analyzers
Probe Type for either sensor set to pH
or
Probe Type
for both sensors set to Redox or ORP and Enable Cals for either sensor set to Yes (Section 5.3) –
see Section 4.1, page 19.
Probe Type for both sensors set to Redox or ORP and Enable Cals for both sensors set to No (Section 5.3) and
Alter Sec. Code not set to zero (Section 5.8) – see Section 5.1, page 28.
Probe Type for both sensors set to Redox or ORP and Enable Cals for both sensors set to No (Section 5.3) and
Alter Sec. Code set to zero (Section 5.8) – see Section 5.2, page 29.
SENSOR CAL.
Security Code
CONFIG. DISPLAY
SENSOR CAL.
Security Code
CONFIG. DISPLAY

ABB AX400 Series Specifications

General

Display	LCD with backlight
Output	4 to 20 mA, HART
Process connection	Flanged
Lining material	PTFE, PFA
Electrode material	Stainless steel, titanium
Communication	HART
