ABB AX400 Series User Manual

Single and dual input analyzers for pH/Redox (ORP)
AX416, AX436, AX460, AX466 & AX468 7 Calibration
IM/AX4PH Rev. P 57
7.3 Factory Settings
Fig. 7.2 Overall Factory Settings Chart
FACTORY SETTINGS Factory Set Code
Cal. Sensor A
A:mV Zero (-1V)
A:mV Span (+1V)
A:T.Zero (100R)
A:T.Span (150R)
Cal. Sensor B
B:T.Zero (100R)
B:T.Span (150R)
Cal. Output 1
O1: Adjust 4mA
O1: Adjust 20mA
To OPERATING PAGE
A:T.Zero (1K0)
B:T.Zero (1K0)
A:T.Span (1K5)
B:T.Span (1K5)
Available only if the Option Board is fitted
and Analog features enabled  see page 61
Key
Cal. Output 3 Cal. Output 4
O3: Adjust 4mA O4: Adjust 4mA
O3: Adjust 20mA O4: Adjust 20mA
Cal. Output 2
O2: Adjust 4mA
O2: Adjust 20mA
Use the Sidescroll Key to scroll through the Pages within each Menu
Use the Menu
Key to scroll
through
the Menus
Use the Downscroll
Key to scroll through
the Frames
within each Page
Section 7.3, Page 58
A:T.Span (5K0)
A:T.Zero (2K0)
B:mV Span (+1V)
B:T.Zero (2K0)
B:T.Span (5K0)
B:mV Zero (-1V)
Dual input analyzer only
Alter Fact.Code
Option Board
Note. The Option Board page is
displayed only if the option board is fitted.
