ABB AX400 Series User Manual

Single and dual input analyzers for pH/Redox (ORP)
AX416, AX436, AX460, AX466 & AX468 5 Programming
IM/AX4PH Rev. P 41
5.8 Configure Security
5.9 Configure Logbook
Alter Security Code
Set the security code to a value between 0000 and 19999.
Alter Calibration Code
Set the sensor calibration access code to a value between 0000 and 19999.
Return to main menu.
Option board fitted and analog features enabled (see Section 7.3, page 57) – see
Section 5.9, page 41.
Alter Sec. Code
0000
Alter Cal. Code
0000
CONFIG. SECURITY
-----
CONFIG. LOGBOOK
CONFIG. SECURITY
Alter Sec. Code
Note. The Configure Logbook function is available only if the option board is fitted and analog features enabled – see Section
7.3, page 57.
Configure Logbook
Use the and keys to set the logbook
On or Off.
If Off is selected, all data entries in the logbook are cleared.
Return to main menu.
See Section 5.10, page 42.
Logbook
-----
CONFIG. LOGBOOK
-----
TEST/MAINTENANCE
CONFIG. LOGBOOK
Off
On
