Single and dual input analyzers for pH/Redox (ORP)
AX416, AX436, AX460, AX466 & AX468 5 Programming
IM/AX4PH Rev. P 43
Automatic Time
If required, set a time period between 1 and 6 hours, in 30 minute increments, for
which the outputs are held when Hold Outputs is set to Auto.
At the default setting of Off, changes in relay action and analog outputs are inhibited
during sensor calibration and released automatically at the end of the procedure.
If a time is set, changes in relay action and analog outputs are inhibited during sensor
calibration, but if the calibration is not completed within the set time, the calibration is
aborted, the display returns to the Operating Page and CAL. ABORTED is displayed.
Continued below.
See Section 7.3, page 57.
Load/Save Configuration
Select whether a configuration is to be loaded or saved.
Note. If
No is selected, pressing the key has no effect.
Return to main menu.
See Section 7.3, page 57.
Load User/Factory Configuration
Note. Applicable only if
Load/Save Config is set to Yes.
Factory Config.
Save User Config.
Load User Config.
–
–
–
resets all the parameters in the
Configuration Pages to
the Company Standard.
saves the current configuration into memory.
reads the saved user configuration into memory.
User Config. and Factory Config. are displayed alternately if a User Configuration has
been saved previously. Use the and keys to make the required selection.
Press to Set and Press to Abort are shown alternately on the lower display line.
Press the appropriate key to load/save the configuration or abort the changes.
Load/Save Config
-----
-----
Yes
No
Load
Save
User Config.
Factory Config.
-----
Press To Set.
Press To Abort
TEST/MAINTENANCE
Yes
FACTORY SETTINGS
TEST/MAINTENANCE
Automatic Time
Hrs
30
Mins
FACTORY SETTINGS
Load/Save Config
Maintenance
1
Hold Outputs
set to Auto.
To Next Page
