Single and dual input analyzers for pH/Redox (ORP)
AX416, AX436, AX460, AX466 & AX468 9 Specification
66 IM/AX4PH Rev. P
Mechanical Data
Wall-/Pipe-mount versions
IP65 (not evaluated under UL certification)
Dimensions 192 mm high x 230 mm wide x 94 mm deep
(7.56 in. high x 9.06 in. wide x 3.7 in. deep)
Weight 1 kg (2.2 lb)
Panel-mount versions
IP65 (front only)
Dimensions 96mm x 96mm x 162mm deep
(3.78 in. x 3.78 in. x 6.38 in. deep)
Weight 0.6kg (1.32 lb)
Cable Entry Types
Power Supply
Voltage requirements
100 to 240 V AC 50/60 Hz
(90 V Min. to 264 V Max. AC)
12 to 30 V DC
Power consumption
10 W
Insulation
Mains to earth (line to ground) 2 kV RMS
Environmental Data
Operating temperature limits
–20 to 55 °C (–4 to 131 °F)
Storage temperature limits
–25 to 75 °C (–13 to 167 °F)
Operating humidity limits
Up to 95 %RH non condensing
EMC
Emissions and immunity
Meets requirements of:
EN61326 (for an industrial environment)
EN50081-2
EN50082-2
Approvals, Certification and Safety
Safety approval
UL
CE Mark
Covers EMC & LV Directives (including latest version EN 61010)
General safety
EN61010-1
Overvoltage Class II on inputs and outputs
Pollution category 2
Languages
Languages configurable:
English
French
German
Italian
Spanish
DS/AX4PH–EN Rev. K
Standard 5 or 7 x M20 cable glands
North American 7 x knockouts suitable for
1
/2 in. Hubble gland
