Chapter 4 – Twelve–Pulse Serial / Sequential Configurations with DCS 600
II F2
4 - 16 DCS 600 Manual for 12 – Pulse Operation
Voltage measurement
The voltage measurement can be done by high ohmic hardware
(solution 1) or by AC and DC transducer (solution 2), but the
scaling is different from the usual 12-pulse serial configuration.
Solution 1 for sandwich configuration:
Rated line (supply)
voltage [V]
SDCS-PIN-51
voltage coding *)
Software coding
S CON NOM VOLT
(42.08)
200 … 500 **) 500 500
500 … 600 600 600
500 … 690 690 690
690 … 800 790 800
800 … 1000 1000 1000
*) See Manual „Technical Data“ (resistors W1 … W 26)
**) No changes of voltage coding are required for 400 V and 500 V
standard converters of size C4!
Solution 2 for sandwich configuration:
Hardware
Terminals / Settings
Rated line
(supply)
voltage
[V]
AC transducer
[terminals *)]
DC transducer
[position **)]
Software
coding
S CON
NOM VOLT
(42.08)
200 … 500 500 (6 – 12 – 18) 675 (6) 500
500 … 600 600 (7 – 13 – 19) 810 (5) 600
600 … 690 690 (8 – 14 – 20) 945 (4) 690
690 … 800 790 (9 – 15 – 21) 1080 (3) 800
800 … 1000 1000 (10 – 17 – 23) 1350 (1) 1000
*) Terminals of part No. 3AST 47 8002 D1
**) Position of part No. DCA 001 9214
