Chapter 6 StartUp Instructions
DCS 600 Manual for 12 Pulse Operation
II F2
6 - 7
CAUTION: it is absolutely essential that the applicable
accident prevention regulations must be ob-
served by the user (in this context, please also
read the section entitled "Safety Instructions")!
6.3.2 Commissioning of a 12 pulse serial configuration
Commissioning of a 12 pulse serial configuration is carried out
after complete electrical installation of the system.
Before commissioning is continued further recommendations
should be taken into consideration:
- Follow the instructions given in the corresponding (separate)
documentation Installation Manual.
- Lock the mains circuit breaker when switching on the elec-
tronics power supply for the first time.
- Open the mechanical connection between the DC motor
and the driven machine.
A commissioning mode for 12 pulse serial operation is not imple-
mented. The armature autotuning procedure is only applicable with
6 pulse operation.
It is advisable to proceed in three steps:
- First of all, commission each 6 pulse converter separately.
- The parameters in the as-delivered condition are for 6
pulse mode.
- The 12 pulse link V260 of the two converters is not opera-
tive in the 6 pulse mode setting.
For commissioning, please consult the relevant (separate) standard
documentation Operating Instructions DCS 600.
For function test of each converter select single mode or at least
disable the second converter by suppressing the firing pulses.
In addition to this disconnect the non-active unit from the mains and
short cut the DC output.
Master
Commissioning the master converter:
- Isolate the slave and short cut the slave DC output.
- Commission the master converter, in either speed or current
controlled mode depending on the application, as a 6
pulse standard converter.
For how to proceed, please consult the relevant standard
documentation Operating Instructions DCS 600.
