Chapter 4 – Twelve–Pulse Serial / Sequential Configurations with DCS 600
II F2
4 - 10 DCS 600 Manual for 12 – Pulse Operation
Solution 2
:
AC + DC voltage
transducers
The voltage measurement with galvanic isolation (Solution 2) must
also be scaled. The required SDCS-PIN-51 modifications and wi-
ring (Solution 2) are described in a separate manual.
Note: Complete 12 – pulse serial and sequential configurations
including units of the series DCA 600 enclosed con-
verters – as delivered from ABB – already feature the
required scaling and wiring measures as an option.
Hardware
Terminals / Settings
Rated line
(supply)
voltage
[V]
AC transducer
[terminals **)]
DC transducer
[position ***)]
Software
coding
S CON
NOM VOLT
(42.08)
200 … 250 500 (6 – 12 – 18) 675 (6) 500
250 … 300 600 (7 – 13 – 19) 810 (5) 600
300 … 350 690 (8 – 14 – 20) 945 (4) 690
350 … 400 790 (9 – 15 – 21) 1080 (3) 800
400 … 500 1000 (10 – 17 – 23) 1350 (1) 1000
500 … 600 1200 *) 1620 *) 1200
*) Special type of transducer has to be used
**) Terminals of part No. 3AST 47 8002 D1
***) Position of part No. DCA 001 9214
