Page #58 background image
Chapter 6 StartUp Instructions
II F2
6 - 8 DCS 600 Manual for 12 Pulse Operation
Slave
Commissioning the slave converter:
- Isolate the master and short cut the master DC output.
- Commission the slave converter under current control as a
6 pulse standard converter.
For how to proceed, please consult the relevant standard
documentation Operating Instructions DCS 600.
12 pulse serial
mode
Commissioning the 12 pulse operation:
- Set the parameters for 12 pulse mode (15.16, 15.22,
47.09, )
(see Chapter 4 TwelvePulse Serial / Sequential
Configurations with DCS 600).
- Connect power sections of 12 pulse master and slave to
the mains supply.
- Check the settings of the two limits for continuous current
flow, and re-optimize the current controller parameters (the
current controller self-setting function cannot be used here).
- The result of the armature autotuning (6 pulse mode) can
be used also for the 12 pulse configuration:
ARM_L (41.11) 12 pulse serial = 0.5 x (41.11) 6 pulse
ARM_R (41.12) 12 pulse serial = 0.5 x (41.12) 6 pulse
Note: The continuous current flow limits are different for
6 pulse and 12 pulse motor current!
Remaining procedures for full operation:
- Optimize the speed controller parameters in the master.
- Set/check the parameters for the monitoring features.
- Check the fault signals and the safety shutdown functions.
- Block Local Operation CDP 312 Panel for slave (16.04).
