NoteAction
DANGER
Turn off all:
• electric power supply
• hydraulic pressure supply
• air pressure supply
to the robot, before entering the robot
working area.
2
CAUTION
The cable package is sensitive to mechan-
ical damage. Handle it with care in order
to avoid damaging the cabling or the con-
nectors.
3
SW-cabling:
xx1500002812
Disconnect hose and cable connectors on
the connection plate.
4
MH-cabling:
xx1500003038
Continues on next page
