FUNCTIONS AND SPECIFICATIONS
14 FOX61xLEDE1
Protection r3a
-SNCP between any 2 P12 or P0-nc signals from the PBUS
- SNCP protection modes - 1+1 unidirectional, revertive
- 1+1 unidirectional, non revertive
- 1+1 bidirectional, revertive
- 1+1 bidirectional, non revertive
Alarm reporting ITU-T X.733 (1992)
Information technology – open systems intercon-
nection – systems management: Alarm reporting
function
r1a
Performance monitoring r1a
- ITU-T G.826 P12 layer
- Layer specific events P12 layer:
- Line code violations
- Positive slips
- Negative slips
Power consumption r1a
- Power supply range V
BAT
refer to "1KHW002460 FOX61x Product Fea-
tures and Characteristics"
- Maximum current consumption, I
VBAT
V
BAT
= -48 V
0.1 A
- Maximum total power requirement from battery, P
TOT
V
BAT
= nominal voltage
4 W
Mechanical parameters r1a
- Construction practice 19 inch
- Height of unit (1 HU = 44.45 mm) 6 HU
- Width of unit (1 TE = 5.08 mm) 4 TE (1 slot)
- Size of the PCB (H x D) 233 mm x 220 mm
- Weight 360 grams
- RoHS Directive 2002/95/EC of the European Parliament
and of the Council of 27.1.2003 on the Restriction
of the use of certain hazardous substances in elec-
trical and electronic equipment
- WEEE Directive 2002/96/EC of the European Parliament
and of the Council of 27.1.2003 on waste electrical
and electronic equipment
Reliability r1a
- Calculated MTTF at 35 °C (MIL-HDBK-217F) 121 years
Emission refer to "1KHW002460 FOX61x Product Fea-
tures and Characteristics"
r1a
Immunity refer to "1KHW002460 FOX61x Product Fea-
tures and Characteristics"
r1a
Safety refer to "1KHW002460 FOX61x Product Fea-
tures and Characteristics"
r1a
Ambient conditions refer to "1KHW002460 FOX61x Product Fea-
tures and Characteristics"
r1a
Table 3: Functions and specifications (continued)
Feature Rating or standard Release
