Table 19: AP: / unit-x / port-y / chan-z, Configuration - CTP
Operation Name Parameter Name Range Description / Details
CTP Configuration Layer Rate P12 Unstructured 2048 kbit/s.
P0_nc Structured n x 64 kbit/s.
n 0 … 2 characters Number of channel timeslots (valid for P0_nc
only).
Timeslot(s) 0 … 64 characters Occupied timeslots in the structured P12 signal
(valid for P0_nc only).
Connected to CTPs Connection Index 0 … 65‘535 Index of a connection assigned to the channel.
Without a connection the parameter is empty
Local Role z-End The channel is the ending point of a connection.
Please refer to "1KHW002467 FOX61x TDM
Services".
a-End Working The channel is the working starting point of a
protected or unprotected connection.
a-End Protecting The channel is the protecting starting point of a
protected connection.
Remote CTP <MO address> Address string of a connections remote end.
Without a connection the parameter is empty
Remote Role z-End The CTP at the connections remote end is the
ending point of a connection.
Please refer to "1KHW002467 FOX61x TDM
Services"
a-End Working The CTP at the connections remote end is the
working starting point of a protected or unpro-
tected connection.
a-End Protecting The CTP at the connections remote end is the
protecting starting point of a protected connec-
tion.
Directionality Bidirectional Directionality of the connection.
Unidirectional
z-End Configuration Revertive Protection
Switching
Enable revertive protection switching.
The z-End will preferably select the working a-
End.
Non-revertive protection switching is only availa-
ble for channels with the number of timeslots
n=1.
Non-revertive protection switching for n>1 will be
available in a future release,
CAS AIS Supervi-
sion
Use CAS AIS as protection switching criterion.
CAS AIS supervision is only applicable with P0-
nc.
Switch-Over Log-
ging
Enable the logging of the protection switch-over
events.
