ABB MagMaster - Page 13

11
DS 2
IC 2 CD 1 CD 2
SIG GND DS 1 SIG 1
Grey Coax
Pink Inner (SIG 2)
Screen (DS 2)
Red
(CD 1)
Yellow
(CD 2)
White Coax
Blue Inner (SIG 1)
Screen (DS 1)
Drive
Connection
Cable Screen Connections
Drain Wire (ESCRN)
Signal
Connection
Gnd
Connection
Violet (SIG GND)
DS 2
IC 2 CD 1 CD 2
SIG GND DS 1 SIG 1
Grey Coax
Pink Inner (SIG 2)
Screen (DS 2)
Red
(CD 1)
Yellow
(CD 2)
White Coax
Blue Inner (SIG 1)
Screen (DS 1)
Drive
Connections
Ground Wire
(Safety Earth)
Violet
Signal
Connections
3 ELECTRICAL INSTALLATION…
North American Wiring Practice
…3.3.2 Transmitters (All versions)
Fig. 3.13 Sensor Cable Connections at the Transmitter (Remote version)
Fig. 3.14 Sensor Cable Connections at the Transmitter (North American Wiring Practice)
