ABB MagMaster - 3 ELECTRICAL INSTALLATION; 3.1 Grounding

5
Insulating Sleeve
and Washer
(not provided)
Supplied Bonding Cables
Insulated connecting wire
(not included). Must be
adequately rated to carry
cathodic currents.
Gasket
Gasket
Grounding Ring
Grounding Rings
Common Ground
(Plant bonding)
>4mm
2
(<10 AWG)
Copper Wire
Detail of grounding
rings required for
BOTH flanges
>4mm
2
(<10AWG)
Copper Wire
Common Ground
(Plant bonding)
Supplied Bonding Cables
Fig. 3.1 Pipelines
Fig. 3.2 Pipelines with Cathodic Protection
3 ELECTRICAL INSTALLATION
3.1 Grounding (Fig. 3.1, 3.2)
