ABB MagMaster - 3.4.6 Computer Connection

16
MagMaster
Transmitter
TX - SIG
TX + SIG
0VC
RX - SIG
RX + SIG
MagMaster
Transmitter
Link
TX - SIG
TX + SIG
0VC
RX - SIG
RX + SIG
MagMaster
TERMINALS
TX-SIG
TX+SIG
RX-SIG
RX+SIG
0VC
–
–
–
RS422 Connection
NAME
RX DATA -
RX DATA +
TX DATA -
TX DATA +
SIGNAL GROUND
DCD
DTR
DSR
APPLE Connector
(8 Pin MC)
5
8
3
6
4
7
1
2
CONNECT TO
Link
together
Link
together
9-Pin
PC
Connector
2
–
3
5
(linked)
4
link
6 together
7 link
8 together
MagMaster
TERMINALS
TX-SIG
TX+SIG
RX-SIG
RX+SIG
0VC
–
–
–
–
CONNECT TO
RS232
Name
RXD
–
TXD
GND
(linked)
DTR
link
DSR together
RTS link
CTS together
25-Pin
PC
Connector
3
–
2
7
(linked)
20
link
6 together
4 link
5 together
Hygienic
Adaptor
Cable
Red
–
Blue
Yellow
Green
–
–
–
–
…3 ELECTRICAL INSTALLATION
3.4.6 Computer Connection – Fig. 3.22 and 3.23
Information. RS422/423 option is electrically isolated from all other MagMaster connections.
Fig. 3.22 RS 422 Connections (Balanced)
Fig. 3.23 RS 423 Connections (Single Ended or RS 232)
