ABB MagMaster - Cable (Alternative Type - North American Wiring Practice); Cable Glands (IEC Installation Practice)

7
Signal Core/Wires
Inner Insulation (Pink)
Conductive Layer (Black)
Screen
Insulation (Grey)
Foil Screen
Signal Core/Wires
Inner Insulation (Blue)
Conductive Layer (Black)
Screen
Insulation (White)
Foil Screen
Red
Violet
Green/Yellow
Outer Jacket
Outer Drain Wire
Screen
Yellow
Grey Coaxial Core/Wires White Coaxial Core/Wires
Cable - Part No. STT3350
Red
Yellow
Outer
Insulation
Length for
Probe Head
Length for
Transmitter
Grey covered coax
Inner to SIG2. Screen to DS2
Violet to SIG GND
White covered coax
Inner to SIG1. Screen to DS1
Overall screen drain
wire to ESCRN
5
4
Inches
32
1
0
0
50
Millimetres
100
'O'-Ring
3 ELECTRICAL INSTALLATION…
3.2.2 Cable (Alternative Type – North American Wiring Practice)
3.2.3 Cable Glands (IEC Installation Practice)
Warning.
• Rigid conduit must not be fitted to
the transmitter.
• Transmitter conduit adaptors must
incorporate a face seal.
Fig. 3.5 Cable Identification (North American Wiring Practice)
Fig. 3.6 Cable Preparation (North American Wiring Practice)
Fig. 3.7 Cable Gland
(IEC Installation Practice)
