ABB MagMaster - Profibus Connections

18
SUPPLY 11V — 40V DC (Max)
DC Supply
Negative to –
–
+
>4mm
2
(<10 A.W.G.)
Copper Wire
External
Internal
Positive to +
ABB Limited
Transmitter Label
…3 ELECTRICAL INSTALLATION
3.4.8 Profibus Connections
Refer to the separate manual (IM/MM/PBS) for details.
Fig. 3.25 Power Supply Connections (DC Version Transmitter)
