…SPECIFICATION
Common
mA
Forward
Reverse
Choice of
9 alarms
<21mA, 16V
<800Hz, <35V open collector
square wave, or fixed pulse
width <2.5s, 250mA
<35V, >250mA open collector
Contact closure or logic input
Totalizer reset
Dual range selection
Output hold
Drive to zero
RS232
(local only)
9-pin D-connector (PC compatible)
Dual analog (optional)
Non-active output is 4mA or 0mA
Optional (For blind & 2-line display units)
Optional (For keypad units)
Dual mA
Dual analog
Non-active output is 4mA or 0mA
Galvanic isolation to 50V DC between analog pulse/alarm
and earth/ground
Profibus DP v0
Dual mA
HART
Output/Inputs
Mounting
>5 x pipe dia.
minimum
>2 x pipe dia.
minimum
Flow Direction
Sensor Electrodes
45°
maximum
Pipe Connections
