ABB MagMaster - Page 5

3
IP65
(NEMA 4)
80°C (176°F)
Maximum !
–10°C (14°F)
Minimum
Backfill
Metal
Protection
Plate
Supports
Supports
2 MECHANICAL INSTALLATION…
Fig. 2.10 Cable Routing
Fig. 2.11 Within Environmental Rating
Fig. 2.12 Underground
Fig. 2.13 Above Ground
Fig. 2.14 Temperature Difference
Fig. 2.15 Shade
