Parameter overview
CI/FEX300/FEX500-EN FEX300, FEX500 EN - 63
Process Alarm
6
Clear Alarm History
Group Masking
Maintenance Required
Function Check
Out of Specification
Individual Masking
Min Flowrate Alarm
Max Flowrate Alarm
Flow >103%
Com Controller Alarm
TFE Alarm
Empty Pipe Alarm
Alarm Simulation
Off
On
Communication 7
HART
Device Address
HART Tag
HART Descriptor
HART Message
HART Manf. ID
HART Device ID
Last HART Command
Cyclic Data Out
Cyclic Upd. Rate
Cyclic Upd. Select
Flow Group
Outputs Group
Status Group
Coil Group
TX Group
Vol. Totals Group
Electrodes Group
Service Port
Max Baud Rate
HART Access
PROFIBUS PA
PA Addr. (BUS)
Ident Nr. Selector
Comm State
AI1-Q Durchfluss
TOT1-Q Durchfluss
TOT2-Q Durchfluss
AI2-Interner Tot Vor
AI3-Interner Tot Rev
AI4-Diagnose
AI4-Channel
AO-Dichte
DI-Alarm Info
DI-Channel
DO-Cyclic Control
DO-Channel
italics = Parameter can only be changed at the "advanced" password level.
