Parameter overview
CI/FEX300/FEX500-EN FEX300, FEX500 EN - 65
Grounding Check
Grounding Check
Power Spectrum
Amplitude 1 Value
Amplitude 2 Value
Amplitude 3 Value
Amplitude 4 Value
TFE Detector
SIL detector
TFE Detector
Adjust TFE Full
TFE Threshold
TFE Value
Diagnosis Values
SNR Value
Slope Value
Slope Variation
Reference
Signal Ratio
Signal max
Signal min
NV Resets/sec
Amplification Int.
Fingerprints Factory F.P.
Sensor Coil R.
Elec. Coat. QE1
Elec. Coat, QE2
Elec. Imp. E1-GND
Elec. Imp. E2-GND
Tx check CMR
Tx check 5 m/s
Tx check 10 m/s
Startup F.P.
Startup F.P.
Sensor Coil R
Elec. Coat. QE1
Elec. Coat. QE2
Elec. Imp. E1-GND
Elec. Imp. E2-GND
Start Tx Startup F.P
Tx check CMR
Tx check 5 m/s
Tx check 10 m/s
On demand F.P.
Start On demand F.P.
Sensor Coil R
Elec. Coat. QE1
Elec. Coat. QE2
Elec. Imp. E1-GND
Elec. Imp. E2-GND
Start Tx Startup F.P
Tx check CMR
Tx check 5 m/s
Tx check 10 m/s
italics = Parameter can only be changed at the "advanced" password level.

ABB ProcessMaster Specifications

General

Type	Electromagnetic Flowmeter
Liner Material	PTFE, PFA, Polyurethane, Rubber
Electrode Material	Stainless steel, Hastelloy, Tantalum, Titanium, Platinum
Process Connection	Flange, Wafer
Fluid Temperature	-40 to 180 °C (-40 to 356 °F) Depending on liner
Output	4-20 mA, HART, PROFIBUS PA, FOUNDATION Fieldbus
Power Supply	100 to 230 V AC, 24 V AC/DC
Protection Class	IP67
Approvals	ATEX, IECEx, FM, CSA
