t s
k A
B
U U
U
C
D
E
=
⋅
×
− >
>
−
+
GUID-6E9DC0FE-7457-4317-9480-8CCC6D63AB35 V2 EN (Equation 105)
t [s] operate time in seconds
U measured voltage
U> the set value of
Start value
k the set value of
Time multiplier
Table 661: Curve coefficients for the standard overvoltage IDMT curves
Curve name A B C D E
(17) Inverse Curve A 1 1 0 0 1
(18) Inverse Curve B 480 32 0.5 0.035 2
(19) Inverse Curve C 480 32 0.5 0.035 3
Section 11 1YHT530004D05 D
General function block features
830 615 series
Technical Manual
