Name Type Values (Range) Unit Description
INPRO_1 BOOLEAN 0=False
1=True
Reclosing shot in
progress, shot 1
INPRO_2 BOOLEAN 0=False
1=True
Reclosing shot in
progress, shot 2
INPRO_3 BOOLEAN 0=False
1=True
Reclosing shot in
progress, shot 3
INPRO_4 BOOLEAN 0=False
1=True
Reclosing shot in
progress, shot 4
INPRO_5 BOOLEAN 0=False
1=True
Reclosing shot in
progress, shot 5
DISCR_INPRO BOOLEAN 0=False
1=True
Signal indicating that
discrimination time is in
progress
CUTOUT_INPRO BOOLEAN 0=False
1=True
Signal indicating that cut-
out time is in progress
SUC_RECL BOOLEAN 0=False
1=True
Indicates a successful
reclosing sequence
UNSUC_CB BOOLEAN 0=False
1=True
Indicates an
unsuccessful CB closing
CNT_SHOT1 INT32 0...2147483647 Resetable operation
counter, shot 1
CNT_SHOT2 INT32 0...2147483647 Resetable operation
counter, shot 2
CNT_SHOT3 INT32 0...2147483647 Resetable operation
counter, shot 3
CNT_SHOT4 INT32 0...2147483647 Resetable operation
counter, shot 4
CNT_SHOT5 INT32 0...2147483647 Resetable operation
counter, shot 5
COUNTER INT32 0...2147483647 Resetable operation
counter, all shots
SHOT_PTR INT32 0...7 Shot pointer value
MAN_CB_CL BOOLEAN 0=False
1=True
Indicates CB manual
closing during reclosing
sequence
SOTF BOOLEAN 0=False
1=True
Switch-onto-fault
DARREC Enum 1=on
2=blocked
3=test
4=test/blocked
5=off
Status
9.4.10 Technical data
Table 625: DARREC Technical data
Characteristic
Value
Operate time accuracy ±1.0% of the set value or ±20 ms
1YHT530004D05 D Section 9
Control functions
615 series 725
