ABB REF615 G - Signal Outputs SO1, SO2 and SO3 in BIO0006

14
16
15
17
19
18
X110
SO1
SO2
20
22
21
23
24
X110
SO3
SO4
GUID-CBA9A48A-2549-455B-907D-8261E2259BF4 V1 EN
Figure 22: Signal output in BIO0005
3.10.2.4 Signal outputs SO1, SO2 and SO3 in BIO0006
The optional card BIO0006 provides the signal outputs SO1, SO2 and SO3. Signal
outputs SO1 and SO2 are dual, parallel form C contacts; SO3 is a single form C
contact.
