Section 14 Technical data
Table 689: Dimensions
Description Value
Width frame 177 mm
case 164 mm
Height frame 177 mm (4U)
case 160 mm
Depth 201 mm (153 + 48 mm)
Weight complete IED 4.1 kg
plug-in unit only 2.1 kg
Table 690: Power supply
Description Type 1 Type 2
U
aux
nominal 100, 110, 120, 220, 240 V AC,
50 Hz
24, 30, 48, 60 V DC
48, 60, 110, 125, 220, 250 V DC
Maximum interruption time
in the auxiliary DC voltage
without resetting the IED
50 ms at U
n
rated
U
aux
variation 38...110% of U
n
(38...264 V AC) 50...120% of U
n
(12...72 V DC)
80...120% of U
n
(38.4...300 V DC)
Start-up threshold 19.2 V DC (24 V DC * 80%)
Burden of auxiliary voltage
supply under quiescent (P
q
)/
operating condition
DC < 12.0 W (nominal)/< 18.0 W
(max)
AC< 16.0 W (nominal)/< 21.0W
(max)
DC < 12.0 W (nominal)/< 18.0 W
(max)
Ripple in the DC auxiliary
voltage
Max 15% of the DC value (at frequency of 100 Hz)
Fuse type T4A/250 V
1YHT530004D05 D Section 14
Technical data
615 series 871
Technical Manual
