Name Type Values (Range) Unit Description
Variation Ph C FLOAT32 0.00...5.00 xUn Variation magnitude
Phase C
Var Ph C rec time Timestamp Variation magnitude
Phase C time stamp
Variation Dur Ph A FLOAT32 0.000...3600.000 s Variation duration Phase
A
Var Dur Ph A time Timestamp Variation Ph A start time
stamp
Variation Dur Ph B FLOAT32 0.000...3600.000 s Variation duration Phase
B
Var Dur Ph B time Timestamp Variation Ph B start time
stamp
Variation Dur Ph C FLOAT32 0.000...3600.000 s Variation duration Phase
C
Var Dur Ph C time Timestamp Variation Ph C start time
stamp
Var current Ph A FLOAT32 0.00...60.00 xIn Current magnitude
Phase A preceding
variation
Var current Ph B FLOAT32 0.00...60.00 xIn Current magnitude
Phase B preceding
variation
Var current Ph C FLOAT32 0.00...60.00 xIn Current magnitude
Phase C preceding
variation
Time Timestamp Time
Variation type Enum 0=No variation
1=Swell
2=Dip
3=Swell + dip
4=Interruption
5=Swell + Int
6=Dip + Int
7=Swell+dip+Int
Variation type
Variation Ph A FLOAT32 0.00...5.00 xUn Variation magnitude
Phase A
Var Ph A rec time Timestamp Variation magnitude
Phase A time stamp
Variation Ph B FLOAT32 0.00...5.00 xUn Variation magnitude
Phase B
Var Ph B rec time Timestamp Variation magnitude
Phase B time stamp
Variation Ph C FLOAT32 0.00...5.00 xUn Variation magnitude
Phase C
Var Ph C rec time Timestamp Variation magnitude
Phase C time stamp
Variation Dur Ph A FLOAT32 0.000...3600.000 s Variation duration Phase
A
Var Dur Ph A time Timestamp Variation Ph A start time
stamp
Table continues on next page
1YHT530004D05 D Section 10
Power quality measurement functions
615 series 789
