Warning indication Warning code Additional information
Warning
Modbus error
21 Error in the Modbus communication.
Warning
DNP3 error
22 Error in the DNP3 communication.
Warning
Dataset error
24 Error in the Data set(s).
Warning
Report cont. error
25 Error in the Report control block(s).
Warning
GOOSE contr. error
26 Error in the GOOSE control block(s).
Warning
SCL config error
27 Error in the SCL configuration file or the file
is missing.
Warning
Logic error
28 Too many connections in the
configuration.
Warning
SMT logic error
29 Error in the SMT connections.
Warning
GOOSE input error
30 Error in the GOOSE connections.
Warning
GOOSE rec. error
32 Error in the GOOSE message receiving.
Warning
AFL error
33 Analog channel configuration error.
Warning
Unack card comp.
40 A new composition has not been
acknowledged/accepted.
Warning
ARC1 cont. light
85 A continuous light has been detected on
the ARC light input 1.
Warning
ARC2 cont. light
86 A continuous light has been detected on
the ARC light input 2.
Warning
ARC3 cont. light
87 A continuous light has been detected on
the ARC light input 3.
4.3 Time synchronization
The IED has an internal real-time clock which can be either free-running or
synchronized from an external source. The real-time clock is used for time stamping
events, recorded data and disturbance recordings.
The IED is provided with a 48-hour capacitor back-up that enables the real-time clock
to keep time in case of an auxiliary power failure.
Setting Synch Source determines the method how the real-time clock is synchronized.
If set to “None”, the clock is free-running and the settings Date and Time can be used
to set the time manually. Other setting values activate a communication protocol that
provides the time synchronization. Only one synchronization method can be active
at a time but SNTP provides time master redundancy.
1MRS756378 D Section 4
Basic functions
REF615 129
Application Manual
