ABB REF615 Applications Manual

2.1.1 Product version history
IED version Release date Product history
1.0 20.12.2007 Product released
1.1 02.07.2008 • IRIG-B
• Support for parallel protocols added: IEC 61850
and Modbus
• X130 BIO added: optional for variants B and D
• CB interlocking functionality enhanced
• TCS functionality in HW enhanced
• Non-volatile memory added
2.0 04.03.2009 • Support for DNP 3.0 serial or TCP/IP
• Support for IEC 60870-5-103
• Voltage measurement and protection
• Power and energy measurement
• New standard configurations E and F
• Disturbance recorder upload via WHMI
• Fuse failure supervision
2.1.2 PCM600 and IED connectivity package version
Supported tools:
• Protection and Control IED Manager PCM600 Ver. 2.0 SP2 or later
• REF615 Connectivity Package Ver. 2.0
• Parameter Setting Tool
• Disturbance Handling Tool
• Signal Monitoring Tool
• Signal Matrix Tool
• Communication Management Tool
• Firmware Update Tool
• IED Configuration Migration Tool (ICM)
• Lifecycle Traceability Tool
Download connectivity packages from the ABB web site http://
www.abb.com/substationautomation
2.2 Operation functionality
2.2.1 Standard configurations
The IED is available with six alternative standard configurations. The table indicates
the functions supported by the different IED configurations.
Section 2 1MRS756378 D
REF615 overview
16 REF615
Application Manual

ABB REF615 Specifications

General

Type	Feeder Protection Relay
Rated Frequency	50/60 Hz
Rated Current	1 A / 5 A
Communication Protocols	IEC 61850, Modbus, DNP3
Mounting	DIN-rail mounting
Operating Temperature Range	-25°C to +55°C
Protection Functions	Overcurrent, Earth-fault, Thermal overload
Inputs	3-phase current, 3-phase voltage
Enclosure	IP54 (front), IP20 (back)
