Functionality A B C D E F
Three-phase undervoltage, instance 1 - - - - - ●
Three-phase undervoltage, instance 2 - - - - - ●
Three-phase undervoltage, instance 3 - - - - - ●
Three-phase inrush current detection ● ● ● ● ● ●
Arc protection with three sensors ￮ ￮ ￮ ￮ ￮ ￮
Control
Circuit breaker control with basic interlocking
1)
● ● ● ● ● ●
Circuit breaker control with extended interlocking
2)
- ● - ● ● ●
Auto-reclosing of one circuit breaker ￮ ￮ ￮ ￮ ￮ ￮
Supervision and monitoring
Fuse failure supervision - - - - ● ●
Current circuit supervision - - - - ● ●
Circuit breaker condition monitoring - ● - ● ● ●
Trip-circuit supervision of two trip circuits ● ● ● ● ● ●
Disconnector position indication - ● - ● ● ●
Earthing switch position indication - ● - ● ● ●
Measurement
Transient disturbance recorder ● ● ● ● ● ●
Three-phase current ● ● ● ● ● ●
Current sequence components ● ● ● ● ● ●
Three-phase voltage - - - - ● ●
Voltage sequence components - - - - ● ●
Residual current ● ● ● ● ● ●
Residual voltage ● ● - - ● ●
Power, including power factor - - - - ● ●
Energy - - - - ● ●
● = Included,○ = Optional at the time of the order
1) Basic interlocking functionality: Closing of the circuit breaker can be enabled by a binary input signal. The actual interlocking scheme is
implemented outside the IED. The binary input serves as a “master interlocking input” and when energized it will enable circuit breaker
closing.
2) Extended interlocking functionality: The circuit breaker interlocking scheme is implemented in the IED configuration, based on primary
equipment position information (via binary inputs) and the logical functions available. The signal matrix tool of PCM600 can be used for
modifying the interlocking scheme to suit your application.
2.2.2 Optional functions
The optional functions available in the IED are:
Section 2 1MRS756378 D
REF615 overview
18 REF615
Application Manual
