LED Default usage
1 Non-Directional Overcurrent Operate
2 Non-Directional Earth fault Operate
3 Sensitive Earth fault Operate
4 Negative Seq. Overcurrent/Phase Discontinuity Operate
5 Thermal Overload Alarm
6 Breaker Failure Operate
7 Disturbance Recorder Triggered
8 Circuit Breaker Condition Monitoring Alarm
9 Trip Circuit Supervision Alarm
10 ARC Protection Operate
11 Auto Reclose in Progress
3.6.3 Functional diagrams
The functional diagrams describe the default input, output, alarm LED and function-
to-function connections. The default connections can be viewed with SMT and
changed according to the application requirements, if necessary.
The analog channels, measurements from CTs and VTs, have fixed connections
towards the different function blocks inside the IED’s standard configuration.
Exceptions from this rule are the 12 analog channels available for the disturbance
recorder function. These channels are freely selectable and a part of the disturbance
recorder’s parameter settings, thus not included in the SMT functionality.
The analog channels are assigned to different functions as shown in the functional
diagrams. The common signal marked with 3I represents the three phase currents.
The signal marked with I
0
represents the measured residual current, via a summation
connection of the phase current transformers.
3.6.3.1 Functional diagrams for protection
The following functional diagrams describe the IED’s protection functionality in
detail and according to the factory set default connections in SMT.
Section 3 1MRS756378 D
REF615 variants
70 REF615
Application Manual
