3.7 Standard configuration E including directional earth-
fault protection with phase-voltage measurement
3.7.1 Applications
The standard configuration for directional earth-fault protection is mainly intended
for cable and overhead line feeder applications in isolated and resonant-earthed
distribution networks. The IED with this standard configuration is delivered from the
factory with default settings and parameters. The end-user flexibility for incoming,
outgoing and internal signal designation within the IED enables this configuration to
be further adapted to different primary circuit layouts and the related functionality
needs by modifying the internal functionality using PCM600.
3.7.2 Functions
Table 17: Functions included in the REF615 standard configuration including directional earth-
fault protection with phase voltage measurement
Function IEC 61850 IEC ANSI
Three-phase non-directional overcurrent
protection, low stage
PHLPTOC1 3I> 51P-1
Three-phase non-directional overcurrent
protection, high stage, instance 1
PHHPTOC1 3I>> (1) 51P-2 (1)
Three-phase non-directional overcurrent
protection, high stage, instance 2
PHHPTOC2 3I>> (2) 51P-2 (2)
Three-phase non-directional overcurrent
protection, instantaneous stage
PHIPTOC1 3I>>> 50P/51P
Arc protection ARCSARC1
ARCSARC2
ARCSARC3
ARC (1)
ARC (2)
ARC (3)
50L/50NL (1)
50L/50NL (2)
50L/50NL (3)
Directional earth-fault protection, low stage,
instance 1
DEFLPDEF1 I
0
> → (1) 67N-1 (1)
Directional earth-fault protection, low stage,
instance 2
DEFLPDEF2 I
0
> → (2) 67N-1 (2)
Directional earth-fault protection, high stage DEFHPDEF1 I
0
>> → 67N-2
Transient/intermittent earth-fault protection INTRPTEF1 I
0
> → IEF 67NIEF
Non-directional earth-fault protection, high
stage, calculated I
0
current (Double earth-fault
protection)
EFHPTOC1 I
0
>> 51N-2
Negative-sequence overcurrent protection,
instance 1
NSPTOC1 I
2
> (1) 46 (1)
Negative-sequence overcurrent protection,
instance 2
NSPTOC2 I
2
> (2) 46 (2)
Phase discontinuity PDNSPTOC1 I
2
/I
1
> 46PD
Three-phase inrush detector INRPHAR1 3I2f> 68
Three-phase thermal protection for feeders,
cables and distribution transformers
T1PTTR1 3Ith> 49F
Table continues on next page
