Software options #3 Notes and Rules

No option X

All fields in the ordering

form do not need to be

filled in

Restricted earth fault protection, low

impedance

Note: A01 only for A40/

B40, 2 blocks already

included

High impedance differential protection - 3

blocks

Note: A02, B12, B13 and

B14 not in A10 and A25.

Note: Only one of B12 /

B13 to be selected.

Transformer distance protection,

quadrilateral

Transformer distance protection, mho B

Underimpedance protection for generators

and transformers

Thermal overload protection C

Note: Not in A10 and

A25, 1 block already

included in A10, A30 and

B30. 2 blocks already

included in A40 and B40.

Sensitive directional residual overcurrent

and power protection

Note: C16 not in A10

Directional power protection C

Note: C17 not in A10/A25

Current protection VCTR C

Note: Only for A25

Four step directional negative phase

sequence overcurrent protection - 2 blocks

Note: Only for

A10/A30/B30

Four step directional negative phase

sequence overcurrent protection - 3 blocks

Note: Only for A40/B40

Voltage protection, 1 bus D

Note: D01 only for A10,

A30 and B30, 1 block

already included in A30

and B30

Voltage protection, 2 buses D

Note: D02 only for A25,

A40 and B40, 1 block

already included in A40

and B40

Overexcitation protection, 2 winding D

Note: Only for A30 and

B30

Overexcitation protection, 3 winding D

Note: Only for A40 and

B40

Frequency protection - station E

Note: E01 not in A25

General current and voltage protection F0

Note: F02 not in A10/A25

Fuse failure supervision based on voltage

difference

Synchrocheck - 2 circuit breakers H

Note: Only for B30

1 block already included

in B30

Synchrocheck - 3 circuit breakers H

Note: Only for A40

1 block already included

in A40

Synchrocheck - 4 circuit breakers H

Note: Only for B40

1 block already included

in B40

Apparatus control 30 objects H

Note: H09 not in A10

Voltage control, single transformer H

Note: Only one of H11/

H15. H11/H15 not in

A10/A25

Voltage control, parallel transformers H

Voltage control, single transformer, 2 control

blocks

Note: H16, H18 only for

A25/A40/B40

2 blocks of H16/H18

already included in A25

Only one of H16 / H18 to

be selected

Voltage control, parallel transformers, 2

control blocks

Circuit breaker condition monitoring - 12 CB M

Note: M12 only for B30,

M15 only for A30, M16

Transformer protection RET670 2.0

1MRK 504 141-BEN C

Product version: 2.0

116 ABB
